UV Lamps & Quartz Sleeves – Replacement Parts for UV Water Disinfection Systems
Keep your UV purification systems running efficiently with high-quality replacement UV lamps and quartz sleeves from AMPAC Water Systems.
Designed to neutralize bacteria, viruses, and other harmful pathogens, these components ensure your water stays microbiologically safe and compliant with health standards.
What Are UV Lamps & Sleeves Used For?
UV disinfection is a chemical-free method of sterilizing water by exposing it to ultraviolet light (254nm wavelength), which destroys microorganisms at the DNA level. Quartz sleeves protect the lamp from water while allowing UV rays to pass through. Replacing both regularly is essential for optimal disinfection performance.
Available UV Lamps & Sleeve Models
| Part Type | Description | Model | Manufacturer | Price | Product Link |
|---|---|---|---|---|---|
| UV Lamp | Replacement Lamp for LB5-151B | RL-999 | Luminor | $145.00 | View Product |
| UV Sleeve | Quartz Sleeve for LB5-151B | RQ-999 | Luminor | $115.00 | — |
| UV Controller | UV Controller for LB5-151B | RC-B56.01 | Luminor | $335.00 | — |
| UV Lamp | Lamp for S-5Q-PA | S463RL | VIQUA | $115.00 | — |
| UV Lamp | Lamp for SPV-2.5, SP150-HO | S150RL-HO | VIQUA | $115.00 | — |
| UV Lamp | 843mm LPLO 254nm Lamp | S36-RL | VIQUA | $145.00 | — |
| UV Lamp | UV Lamp for S2Q UV Units | S330RL | VIQUA | $115.00 | — |
| Quartz Sleeve | Sleeve for UV Model VH200 | QS-001 | VIQUA | $64.50 | — |
| Quartz Sleeve | Quartz Sleeve for S2Q-PA | QS-330 | VIQUA | $65.00 | — |
| Quartz Sleeve | Sleeve for VH150 | QSO-150 | VIQUA | $62.00 | — |
| Quartz Sleeve | Replacement Sleeve for S-5Q-PA | QS-463 | VIQUA | $66.50 | — |
Benefits of Using Genuine UV Replacement Parts
- Maintains full disinfection efficiency (99.99% pathogen removal)
- Quartz sleeves provide clear UV transmission with no chemical contact
- Replacement lamps ensure consistent 254nm output
- Compatible with industry-standard UV systems
- Long-lasting performance (lamp life 9,000–10,000 hours)
Applications
- Residential whole-house UV systems
- Commercial UV treatment units
- Reverse osmosis & filtration post-treatment
- Food & beverage water purification
- Medical, lab, and dialysis-grade systems
FAQs – UV Lamps & Quartz Sleeves
Q1. How often should I replace my UV lamp?
Every 12 months or 9,000–10,000 hours of use for optimal performance.
Q2. Do quartz sleeves need replacing too?
Yes, sleeves should be cleaned regularly and replaced every 2–3 years or if scratched.
Q3. Will these lamps work in other UV systems?
Only use manufacturer-approved lamps to ensure safety and performance.
Q4. What happens if I don't replace the lamp on time?
The UV intensity will drop, and pathogens may not be fully neutralized.
